Edge Banding Machine RME368E

Edge Banding Machine RME368E

The RME368E is a 8-function edge banding machine,the functions are Pre-milling-Gluing-End cutting-Rough trimming-Fine trimming-Corner Trim-Scrapping -Buffing.

Inquiry Contact

Technical parameters

Model	RME368E
Edge thickness	0.4-3mm
Work piece thickness	10-55mm
Panel length	>120mm
Panel width	>55mm
Feeding speed	18-22m/min
Outline size	6700x1000x1600mm
Weight	2500kg

Video

Characteristic

The RME368E is a 8-function edge banding machine,the functions are Pre-milling-Gluing-End cutting-Rough trimming-Fine trimming-Corner Trim-Scrapping -Buffing.

The Pre-milling function of the edge banding machine is achieved through. Two pieces 2.2KW high speed motor, to do the joint trimming before the gluing, to reduce the adhesive mark on the edge.

The buffing component polishes the edge and removes the sol residue on the workpiece. Edge banding machine polishing device uses a cotton polishing wheel to clean the processed plate. The edge-sealing end surface is smoother through polishing.

You may also be concerned about

The reasons for the deviation of the abrasive belt

The normal swing amplitude and frequency of the abrasive belt have their standard range. If not adjusted properly, the abrasive belt may operate in an abnormal state, causing it to deviate.
Adjustment methods for abrasive belt deviatio

Check and adjust the swing amplitude and frequency of the abrasive belt to ensure they are within the normal range (usually the swing amplitude is 15-20mm and the swing frequency is 15-20 times per minute).
Maintenance and repair of Wide Belt Sander

1.Regularly inspect and replace worn abrasive belts and contact rollers to ensure the sanding effect and processing accuracy.
2. Conduct a thorough cleaning of the equipment, especially regularly removing wood chips and dust from the surface of the sand belt and rollers.
Flow rate adjustment of the spray gun

The power source of the spray gun is controlled by the compressed air pressure valve. The pressure value directly affects the atomization effect of the spray. The working pressure range is 0.3-0.5Mpa.
Cleaning after using the spray painting machine

Pour the cleaning agent into the feeding port of the paint spraying machine, start the paint spraying machine, and let the cleaning agent circulate in the pipeline to clean the paint and dirt inside the pipeline. This process can last for several minutes until the cleaning agent is discharged clearly.
